In the bustling industrial landscape of Kinshasa, Yoane Steel proudly stands as a trusted partner for superior-grade materials. Our dedication lies in providing robust and reliable solutions for the demanding industries across Congo, with our Alloy Steel AISI 52100 bars representing a cornerstone of that commitment. We ensure consistent quality and precise engineering in every bar, empowering your most critical projects with a material forged for exceptional strength and durability right here in the heart of our dynamic city.
The strength of AISI 52100 is rooted in its specific chemistry, which boasts a high chromium content that significantly enhances its hardenability. After proper heat treatment, it develops an outstanding combination of high wear resistance and excellent fatigue strength, allowing it to withstand repeated stress. This alloy maintains good stability and can achieve a very high surface hardness, making it incredibly tough and long-lasting under the most challenging mechanical conditions.
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm To 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Length | 100 mm To 6000 mm Long & Above |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | Round, Square, Hex (A/F),Flate, Rectangle, Billet, Ingot, Forging Supplier |
| Stainless Steel | ASTM A-479, A-182, 304, 304L,304H,304S, 316, 316L,316 Ti, 316H, 309, 310, 310S, 317L, 321, 347, 409, 410, 420, 430, 440, 446, 904L. etc. |
| Duplex Steel | 2205, 31803, 32750, 32760, 2101, 2304. |
| Alloy Steel | A-182 – F5, F9, F11, F12, F21, F22 & F91 |
| Special Grade | Stainless Steel 17-4 PH, Alloy 800, Alloy 600. Hastelloy C276. |
| Carbon Steel | A 105, LF 2, Duplex Steel. |
| Element | Content (%) | ||
| SAE / AISI 52100 | Min | Max | |
| Carbon | C | 0.98 | 1.1 |
| Chromium | Cr | 1.3 | 1.6 |
| Manganese | Mn | 0.25 | 0.45 |
| Silicon | Si | 0.15 | 0.35 |
| Sulfur | S | – | 0.025 |
| Phosphorous | P | – | 0.025 |
| USA | Germany | China | Japan | France | England | Italy | ISO | Czechia | Austria | Sweden | Spain |
| AIAI/ASTM/SAE/UNS | DIN,WN-r | GB | JIS | AFNOR | BS | UNI | ISO | CSN | ONORM | SS | UNE |
| E52100/ G52986 | 100Cr6 (W3) / 1.3505 | GCr15 | SUJ2 | 100C6 | 535A99 | 100Cr6(B1) | SKF3 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Sizes Chart in Milimeter | Sizes in Inch | Thickness Chart In MM | Thickness Chart In Inches |
|---|---|---|---|
| 22 | 7/8 | 17 & 18 | 2/3 – 5/7 |
| 25 | 1 | 5 to 20 | 3/16 – 4/5 |
| 30 | 1-3/16 | 5 to 20 | 3/16 – 4/5 |
| 32 | 1-1/4 | 6 to 20 | 1/4 – 4/5 |
| 35 | 1-3/8 | 5 to 20 | 3/16 – 3/16 |
| 40 | 1-4/7 | 5 to 25 | 3/16 – 1 |
| 45 | 1-7/9 | 5 to 25 | 3/16 – 1 |
| 47 | 1-6/7 | 17,25 & 32 | 2/3, 1 & 1-1/4 |
| 50 | 2 | 5 to 32 | 3/16 – 1-1/4 |
| 55 | 2-1/16 | 5 to 25 | 3/16 – 1 |
| 57 | 2-1/4 | 32 | 1-1/4 |
| 60 | 2-3/8 | 5 to 35 | 3/16 – 1-3/8 |
| 63 | 2-1/2 | 10 to 30 | 3/8 – 1-3/16 |
| 65 | 2-5/9 | 10 to 30 & 35 | 3/8 – 1-3/16, & 1-3/8 |
| 70 | 2-3/4 | 6 to 25 & 40 | 1/4 – 1, & 1-4/7 |
| 75 | 3 | 8 to 25 | 5/16 – 1 |
| 80 | 3-1/8 | 8 to 20 | 5/16 – 4/5 |
| 90 | 3-1/2 | 8 to 20 | 5/16- 4/5 |
| 100 | 4 | 8, 10, 12 | 5/16, 3/8, 1/2 |
You’ll typically find AISI 52100 bars at work in applications where failure is not an option. They are the go-to material for high-performance bearings, gears, and shafts that must endure constant friction and heavy loads. Beyond this, these bars are essential for precision tools, molds, and critical components in machinery across the automotive, aerospace, and manufacturing sectors, consistently delivering reliable performance where superior strength and resistance to wear are absolutely crucial.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
