From the heart of Kinshasa, Yoane Steel stands as a leading manufacturer and supplier, dedicated to supporting the robust infrastructure growth across Congo and beyond. We take pride in producing reliable API 5L Grade B PSL1 pipes, foundational components built to meet the demanding requirements of modern projects. Our commitment lies not just in supplying materials, but in delivering integrity and strength, ensuring that every length of pipe contributes to the safe and efficient development of vital energy and industrial systems.
The composition of API 5L Grade B PSL1 pipe is carefully balanced, primarily consisting of carbon, manganese, and other elements to create a strong yet workable steel. This specific recipe allows the pipe to reach key mechanical properties, including a minimum yield strength of 35,000 psi, which is its ability to resist permanent deformation. It also possesses excellent tensile strength, ensuring it can handle significant internal pressures, making it a dependable choice for a wide array of structural and transport applications.
| API 5l Gr B Psl2 ERW and HFW | 1/2” NB – 24” NB |
| API 5L Gr B SAW | 16″ – 100″ NB |
| API 5L Grade B Psl1 LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| API 5L Grade B Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2″ – 26″) |
| OD | 21.3MM ~ 762MM |
| Killed Carbon Steel API 5L Pipe end | BOE-Beveled One End TOE -Treaded One End, BE -Beveled end, BLE -Bevel large end, BSE -Bevel small end, TBE -Treaded Both Ends, BBE -Bevel both ends, POE -Plain One End, PBE -Plain Both Ends, API 5L Grade B Welded Pipe |
| Wall Thickness of API 5L Grade B Pipe | 4.5mm to 60mm |
| API 5L Grade B Material Cutting Techniques | Sawing, Laser, Burrless Cuts, Tapping, Water-Jet, API 5L Gr B Nace Pipe |
| Different methods used by API 5L Grade B Pipe manufacturers’ | Longitudinally Submerged Arc Welded (LSAW), Cold Drawn Seamless (CDS), 100% X Ray/ Gamma Ray Welded Welded, CDW, Submerged Arc Welded (SAW), Extrusion, Fabricated, Seamless, Electro Fusion Seam Welded (EFSW), Horizontal Submerged Arc Welded (HSAW), Electric Resistance Welded (ERW), Hot Finish Seamless (HFS), API 5L Grade B Schedule 80 Pipe |
| Surface Treatment of API 5L Grb Pipe |
|
| Pipe API 5L Gr B Schedule | SCH-40, SCH-80S, SCH-40S, SCH-10S, SCH-5, SCH-80, SCH160, SCH-XS, SCH-STD, SCH-5S, SCH-10, SCH-XXS, API 5L Gr B Smls Pipe |
| L245 Grade B Pipe Length | 12000mm, 20FT, Single Random Length (SRL), 6000mm, 40FT, DRL, Double Random Length (DRL), 2000mm, Custom Length SRL, 3000mm, API 5L Gr.B PSL2- SAW Pipes |
| Chemical Composition % | ||||||||
| PSL1 | PSL2 | |||||||
| Grade | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) |
| A | 0.22 | 0.90 | 0.03 | 0.03 | 0.22 | 1.20 | 0.025 | 0.015 |
| B | 0.26 | 1.20 | 0.03 | 0.03 | 0.22 | 1.30 | 0.025 | 0.015 |
| X42 | 0.26 | 1.30 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X46 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X52 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X56 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X60 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.45 | 0.025 | 0.015 |
| X65 | 0.26 | 1.45 | 0.03 | 0.03 | 0.22 | 1.65 | 0.025 | 0.015 |
| X70 | 0.26 | 1.65 | 0.03 | 0.03 | 0.22 | 1.85 | 0.025 | 0.015 |
| PSL 1 | |||||
|---|---|---|---|---|---|
| Grade | Tensile Strength(Min.) | Yield Strength(Min.) | Elongation | ||
| MPa | Ksi | MPa | Ksi | E=1944 A 0.2 /U 0.9 | |
| B | 414 | 60 | 241 | 35 | |
| X52 | 455 | 66 | 359 | 52 | |
| X60 | 434 | 63 | 414 | 60 | |
| X65 | 455 | 66 | 448 | 65 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yoane Steel is a top manufacturer and supplier of high-quality API 5L Grade B PSL1 Pipe products in Kinshasa, Congo. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
You’ll most often find API 5L Grade B PSL1 pipe serving as the backbone for conveying oil, natural gas, and water across vast distances in transmission pipelines. Beyond that, its reliability makes it equally suitable for a host of industrial uses, such as structural piling for construction projects, and in various plant settings for process piping. This versatility is why it’s a trusted material for foundational infrastructure, playing a critical role in everything from energy distribution to building the frameworks for new commercial and industrial developments.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
