From the heart of Kinshasa, Yoane Steel proudly serves as your trusted partner for high-performance steel solutions, specializing in the supply of premium ASTM A709-50W Corten steel. We are dedicated to supporting the ambitious infrastructure and architectural projects across Congo and beyond, providing material that not only meets rigorous international standards but is also built to endure. Our commitment is to deliver the strength and distinctive, protective quality of Corten steel, ensuring your structures stand resilient against time and the elements.
This remarkable steel achieves its weather-resistant properties through a specific chemical composition, including elements like copper, chromium, and nickel. When exposed to the atmosphere, it forms a dense, protective rust-like layer that inhibits further corrosion. Mechanically, it is classified as Grade 50W, offering a minimum yield strength of 50 ksi (345 MPa), which provides exceptional structural integrity and durability for demanding applications, balancing high strength with good weldability.
STANDARD: ASTM A709
THICKNESS: 6-100mm
WIDTH: 900-4800mm
LENGTH: 3000-12000mm
GRADES:50W,50WT,50WF
SERVICES: Welding, Forming, Thermal Cutting
| TYPE | THICKNESS (in) | MN (wt %) | C (MAX wt %) | S (MAX wt %) | NI (MAX wt %) | P (MAX wt %) | V (wt %) | SI (wt %) | CR (wt %) | CU (wt %) |
|---|---|---|---|---|---|---|---|---|---|---|
| B | 2.00 – 3.00 | 0.75 – 1.35 | 0.20 | 0.030 | 0.50 | 0.030 | 0.01 – 0.10 | 0.15 – 0.50 | 0.40 – 0.70 | 0.20 – 0.40 |
| A | 0.1875 – 2.00 | 0.80 – 1.25 | 0.19 | 0.030 | 0.40 | 0.030 | 0.02 – 0.10 | 0.30 – 0.65 | 0.40 – 0.65 | 0.25 – 0.40 |
| GRADE | THICKNESS (in) | ELONGATION IN 8″ 2) (MIN %) | TENSILE STRENGTH (MIN ksi) | YIELD STRENGTH 1) (MIN ksi) | ELONGATION IN 2″ 2) (MIN %) |
|---|---|---|---|---|---|
| 50WT | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50W | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50WF | 0.1875 – 2.50 | 18 | 70 | 50 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yoane Steel is one of the most prominent manufacturers and suppliers of superior quality ASTM A709-50W Corten Steel Sheet and Plate in Kinshasa, Congo. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| GRADE | THICKNESS (in) | MIN LONGITUDINAL INDIVIDUAL VALUE 1) (ft-lbs) | MIN LONGITUDINAL AVERAGE ENERGY 1) (ft-lbs) | ZONE 2 TEST TEMP | ZONE 1 TEST TEMP | ZONE 3 TEST TEMP |
|---|---|---|---|---|---|---|
| 50WT | 2.01 – 3.00 | — | 20 | 40 oF | 70 oF | 10 oF |
| 50WT | 0.1875 – 2.00 | — | 15 | 40 oF | 70 oF | 10 oF |
| 50WF | 0.1875 – 2.00 | 20 | 25 | 40 oF | 70 oF | 10 oF |
| 50WF | 2.01 – 2.50 | 24 | 30 |
| GRADE | WIDTH (in) | THICKNESS (in) | LENGTH (in) |
|---|---|---|---|
| 50WT | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50W | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50WF | 72 – 120 | 0.1875 – 2.50 | 240 – 1200 |
The primary use for this material is in the construction of bridges and other major structural frameworks where its high strength and atmospheric corrosion resistance significantly reduce long-term maintenance. Beyond heavy engineering, its unique, evolving aesthetic makes it a favorite in architectural design for building facades, sculptural elements, and landscape features. It’s the ideal choice for creating enduring structures that are as visually striking as they are structurally sound, blending functionality with a distinct, natural character.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
