Strategically located in the bustling industrial landscape of Kinshasa, Yoane Steel has established itself as a trusted partner for robust infrastructure projects across Congo. We take pride in supplying premium Carbon Steel F48 Forged Fittings, known for their exceptional reliability in demanding applications. Our commitment lies in providing durable components that meet rigorous standards, ensuring your piping systems are built for longevity and performance, backed by our local expertise and dependable service.
The strength of Carbon Steel F48 lies in its well-balanced composition, primarily iron and carbon, enhanced with other elements for superior performance. This specific blend gives the fittings excellent mechanical properties, including high tensile strength and good yield strength, allowing them to withstand significant internal pressure and mechanical stress. This inherent toughness makes them resistant to deformation, providing a reliable and long-lasting solution for critical connections.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F48 | 0.06-0.10 | 0.20-0.40 | 1.10-1.40 | ≤ 0.020 | ≤ 0.010 | 1.20-1.70 | 0.20-0.40 | ≤ 0.30 | ≤ 0.25 | 0.02-0.06 | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| F48 | 70 | 82 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F48 Forged Screwed Elbows, Street Elbow, Carbon Steel F48 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F48 Reducing Coupling, Carbon Steel F48 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F48 Threaded Bushing, Carbon Steel F48 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F48 Barrel Nipples, CS F48 Forged Threaded Boss, Carbon Steel F48 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F48 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F48 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F48 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F48 Coupling |
These forged fittings are indispensable in industries where failure is not an option. You will find them forming the backbone of high-pressure piping systems in oil and gas exploration, power generation plants, and complex chemical processing facilities. Their robustness makes them equally vital for heavy-duty water treatment infrastructure and large-scale industrial machinery, ensuring secure and leak-proof connections that endure under challenging conditions for years.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
