In the heart of Kinshasa, Yoane Steel stands as a trusted partner for the region’s builders and fabricators, supplying high-quality materials that fuel progress across the Congo. We specialize in providing robust and reliable S355J2G3 steel sheets and plates, understanding that your projects demand materials that can withstand significant pressure and challenging environments. Our commitment is to deliver not just steel, but the foundational strength for the infrastructure, industry, and ambitions shaping our community, ensuring every piece meets the high standards our clients expect for their most important work.
The S355J2G3 grade is a fine-grained, structural steel known for its excellent balance of strength and formability. Primarily composed of iron with carefully controlled amounts of carbon, manganese, and silicon, it gains its notable toughness through a normalized rolling process. This results in a minimum yield strength of 355 MPa, offering impressive resistance to impact even at lower temperatures. These properties make it a versatile material that is both strong enough for heavy loads and workable enough for various fabrication techniques, from cutting to welding.
| Item | S355J2G3 – Offshore & Structural Steel Plates |
|---|---|
| Technique | hot rolled |
| Thickness | 5mm-150mm |
| Width | 1000mm-4500mm |
| Length | 3000mm-18000mm or as custom’s request |
| Standard | EN 10025-2:2004 |
| Material | S355J2G3 Steel Plates, En 10025-2 Steel Plate |
| Material | Si | Mn | Ni | C | Al | P | Cu | Cr | S | CEQ |
| DIN 1.0570 | 0.55 max. | 1.60 max. | 0.30 max. | 0.20 max. | 0.020 max. | 0.035 max. | 0.30 max. | 0.30 max. | 0.035 max. | 0.45 max. |
| Grade | Tensile(MPa) | (Mpa)Â Min Yield Strength | Elongation(%) | Thickness (mm) | Min Impact Energy | |
| DIN 1.0570 | ||||||
| 450-600 Mpa | 285 -295Mpa | 18% | 101 -200 | -20 | 27J | |
| 450-630 Mpa | 315 -355 Mpa | 18-20% | 8 -100 | -20 | 27J | |
| 450-600 Mpa | 275 Mpa | 17% | 201 -400 | -20 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 4.7 – 51.0 | Thickness (milimeter) |
|---|---|
| 0.47 (0.70) | Max CET(CEV) |
| 0.40 (0.59) | Typ CET(CEV) |
| Plate Thickness (mm) | Weight (kg/m2) |
| 1.06 mm | 12.06 |
| 2.00 mm | 15.07 |
| 2.05 mm | 19.06 |
| 3 mm | 23.06 |
| 3.02 mm | 25.01 |
| 4 mm | 31.04 |
| 5 mm | 39.03 |
| 6 mm | 47.01 |
| 8 mm | 62.08 |
| 10 mm | 78.05 |
| 12.05 mm | 98.01 |
| 15 mm | 118 |
| 20 mm | 157 |
| 22.05 mm | 177 |
| 25 mm | 196 |
| 30 mm | 236 |
| 32 mm | 251 |
| 35 mm | 275 |
| 40 mm | 314 |
| 45 mm | 353 |
| 50 mm | 393 |
| 55 mm | 432 |
| 60 mm | 471 |
| 65 mm | 510 |
| 70 mm | 550 |
| 75 mm | 589 |
| 80 mm | 628 |
| 90 mm | 707 |
| 100 mm | 785 |
| 110 mm | 864 |
| 120 mm | 942 |
| 130 mm | 1051 |
| 150 mm | 1178 |
| 160 mm | 1256 |
| 180 mm | 1413 |
| 200 mm | 1570 |
| 250 mm | 1963 |
| length x Width | Thickness | Mass per Sq m | Â | Length x Width | Thickness | Mass per Sq m |
|---|---|---|---|---|---|---|
| milimeter | milimeter | Kg/m2 | milimeter | milimeter | Kg/m2 | |
| 2000 x 1000 | 3 | 23.055 | 2000 x 1000 | 30.000 | 235.050 | |
| 2500 x 1250 | 3 | 23.055 | 2500 x 1250 | 30.000 | 235.050 | |
| 3000 x 1500 | 3 | 23.055 | 3000 x 1500 | 30.000 | 235.050 | |
| 3660 x 1830 | 3 | 23.055 | 4000 x 2000 | 30.000 | 235.050 | |
| 4000 x 2000 | 3 | 23.055 | 5000 x 1250 | 30.000 | 235.050 | |
| 2000 x 1000 | 4 | 31.040 | 5000 x 2500 | 30.000 | 235.050 | |
| 2500 x 1250 | 4 | 31.040 | 6000 x 2500 | 30.000 | 235.050 | |
| 3000 x 1500 | 4 | 31.040 | 10000 x 2500 | 30.000 | 235.050 | |
| 3660 x 1830 | 4 | 31.040 | 2000 x 1000 | 32.000 | 251.020 | |
| 2000 x 1000 | 5 | 39.025 | 2500 x 1250 | 32.000 | 251.020 | |
| 2500 x 1250 | 5 | 39.025 | 3000 x 1500 | 32.000 | 251.020 | |
| 3000 x 1500 | 5 | 39.025 | 4000 x 2000 | 32.000 | 251.020 | |
| 3660 x 1830 | 5 | 39.025 | 5000 x 2500 | 32.000 | 251.020 | |
| 4000 x 1750 | 5 | 39.025 | 2500 x 1250 | 35.000 | 274.075 | |
| 4000 x 1830 | 5 | 39.025 | 3000 x 1500 | 35.000 | 274.075 | |
| 4000 x 2000 | 5 | 39.025 | 4000 x 2000 | 35.000 | 274.075 | |
| 6000 x 2000 | 5 | 39.025 | 2000 x 1000 | 40.000 | 314.000 | |
| 2500 x 1250 | 6 | 47.010 | 2500 x 1250 | 40.000 | 314.000 | |
| 3000 x 1500 | 6 | 47.010 | 3000 x 1500 | 40.000 | 314.000 | |
| 3000 x 1525 | 6 | 47.010 | 4000 x 1750 | 40.000 | 314.000 | |
| 3660 x 1830 | 6 | 47.010 | 4000 x 2000 | 40.000 | 314.000 | |
| 4000 x 1750 | 6 | 47.010 | 5000 x 2500 | 40.000 | 314.000 | |
| 4000 x 1830 | 6 | 47.010 | 6000 x 2000 | 40.000 | 314.000 | |
| 4000 x 2000 | 6 | 47.010 | 7500 x 2500 | 40.000 | 314.000 | |
| 6000 x 1500 | 6 | 47.010 | 2000 x 1000 | 45.000 | 353.025 | |
| 6000 x 1830 | 6 | 47.010 | 2500 x 1250 | 45.000 | 353.025 | |
| 6000 x 2000 | 6 | 47.010 | 2500 x 1500 | 45.000 | 353.025 | |
| 6000 x 2500 | 6 | 47.010 | 3000 x 1500 | 45.000 | 353.025 | |
| 8000 x 2000 | 6 | 47.010 | 4000 x 2000 | 45.000 | 353.025 | |
| 8000 x 2500 | 6 | 47.010 | 5000 x 2500 | 45.000 | 353.025 | |
| 2000 x 1000 | 8 | 62.080 | 2000 x 1000 | 50.000 | 392.050 | |
| 2500 x 1250 | 8 | 62.080 | 2500 x 1250 | 50.000 | 392.050 | |
| 3000 x 1500 | 8 | 62.080 | 3000 x 1500 | 50.000 | 392.050 | |
| 3660 x 1830 | 8 | 62.080 | 4000 x 2000 | 50.000 | 392.050 | |
| 4000 x 2000 | 8 | 62.080 | 5000 x 2500 | 50.000 | 392.050 | |
| 5000 x 2500 | 8 | 62.080 | 6000 x 2000 | 50.000 | 392.050 | |
| 6000 x 1500 | 8 | 62.080 | 8000 x 2500 | 50.000 | 392.050 | |
| 6000 x 2000 | 8 | 62.080 | 2000 x 1000 | 60.000 | 471.000 | |
| 8000 x 2000 | 8 | 62.080 | 2500 x 1250 | 60.000 | 471.000 | |
| 2000 x 1000 | 10 | 78.050 | 3000 x 1500 | 60.000 | 471.000 | |
| 2500 x 1250 | 10 | 78.050 | 4000 x 2000 | 60.000 | 471.000 | |
| 3000 x 1500 | 10 | 78.050 | 5000 x 2500 | 60.000 | 471.000 | |
| 4000 x 1750 | 10 | 78.050 | 2000 x 1000 | 65.000 | 510.025 | |
| 5000 x 2500 | 10 | 78.050 | 2500 x 1250 | 65.000 | 510.025 | |
| 6000 x 1500 | 10 | 78.050 | 3000 x 1500 | 65.000 | 510.025 | |
| 6000 x 2000 | 10 | 78.050 | 4000 x 2000 | 65.000 | 510.025 | |
| 6000 x 2500 | 10 | 78.050 | 5000 x 2500 | 65.000 | 510.025 | |
| 10000 x 2000 | 10 | 78.050 | 2000 x 1000 | 70.000 | 549.05 | |
| 10000 x 2500 | 10 | 78.050 | 2500 x 1250 | 70.000 | 549.05 | |
| 2000 x 1000 | 12 | 94.020 | 3000 x 1500 | 70.000 | 549.05 | |
| 4000 x 2000 | 12 | 94.020 | 4000 x 2000 | 70.000 | 549.05 | |
| 6000 x 2000 | 12 | 94.020 | 5000 x 2500 | 70.000 | 549.05 | |
| 6000 x 2500 | 12 | 94.020 | 2000 x 1000 | 75.000 | 588.075 | |
| 2000 x 1000 | 12.05 | 98.013 | 2500 x 1250 | 75.000 | 588.075 | |
| 2500 x 1250 | 12.05 | 98.013 | 3000 x 1500 | 75.000 | 588.075 | |
| 3000 x 1500 | 12.05 | 98.013 | 4000 x 2000 | 75.000 | 588.075 | |
| 3050 x 1525 | 12.05 | 98.013 | 5000 x 2500 | 75.000 | 588.075 | |
| 4000 x 1750 | 12.05 | 98.013 | 2000 x 1000 | 80.000 | 628.000 | |
| 4000 x 2000 | 12.05 | 98.013 | 2500 x 1250 | 80.000 | 628.000 | |
| 5000 x 2500 | 12.05 | 98.013 | 3000 x 1500 | 80.000 | 628.000 | |
| 6000 x 1500 | 12.05 | 98.013 | 4000 x 2000 | 80.000 | 628.000 | |
| 6000 x 2000 | 12.05 | 98.013 | 2000 x 1000 | 90.000 | 706.05 | |
| 6000 x 2500 | 12.05 | 98.013 | 2500 x 1250 | 90.000 | 706.05 | |
| 2000 x 1000 | 15 | 117.075 | 3000 x 1500 | 90.000 | 706.05 | |
| 2500 x 1250 | 15 | 117.075 | 4000 x 2000 | 90.000 | 706.05 | |
| 3000 x 1500 | 15 | 117.075 | 5000 x 2000 | 90.000 | 706.05 | |
| 4000 x 1750 | 15 | 117.075 | 2000 x 1000 | 100.000 | 785.000 | |
| 4000 x 2000 | 15 | 117.075 | 2500 x 1250 | 100.000 | 785.000 | |
| 4000 x 2500 | 15 | 117.075 | 3000 x 1500 | 100.000 | 785.000 | |
| 5000 x 2500 | 15 | 117.075 | 4000 x 2000 | 100.000 | 785.000 | |
| 6000 x 2500 | 15 | 117.075 | 5000 x 2500 | 100.000 | 785.000 | |
| 2500 x 1250 | 20 | 157.000 | 2000 x 1000 | 110.000 | 863.050 | |
| 3000 x 1500 | 20 | 157.000 | 2500 x 1250 | 110.000 | 863.050 | |
| 4000 x 2000 | 20 | 157.000 | 3000 x 1500 | 110.000 | 863.050 |
The strength and reliability of S355J2G3 steel make it a cornerstone material for a multitude of demanding applications. You will commonly find it forming the skeletons of modern buildings, sturdy industrial bridges, and heavy-duty support structures where integrity is non-negotiable. Beyond construction, it is essential in manufacturing robust machinery, durable mining equipment, and reliable storage tanks. Its excellent weldability also allows engineers and fabricators to create complex, custom components, making it a preferred choice for projects that require a perfect blend of resilience, versatility, and long-term performance.
