Operating from the heart of Kinshasa, Congo, Yoane Steel is your dedicated partner for specialized steel plates built to withstand the most demanding environments. We take pride in supplying critical materials like SA 516 GR.65N NACE and MR 0103-0175 plates, which are engineered specifically for the unique challenges of the energy and processing sectors. Our commitment is to provide reliable, high-integrity materials that ensure safety and longevity in critical applications across the region and beyond, backed by our deep understanding of local industrial needs.
These specialized plates are crafted with a precise chemical composition that minimizes carbon and other hardening elements, giving them exceptional resistance to sulfide stress cracking. Their mechanical properties are carefully controlled to offer high yield and tensile strength while maintaining excellent toughness and weldability. This deliberate engineering creates a material that is not only strong and durable but also specifically resilient against the corrosive effects found in sour service environments containing hydrogen sulfide.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE and MR 0103-0175 Plates in Kinshasa, Congo. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE and MR 0103-0175 Plates needs!
The primary use for these plates is in the construction of critical equipment for the oil, gas, and petrochemical industries, where safety is paramount. They are essential for fabricating pressure vessels, reactors, and separators that handle corrosive “sour” hydrocarbons. Their robust performance also makes them ideal for energy sector infrastructure and other heavy industrial applications where equipment must endure aggressive conditions without compromising structural integrity, ensuring the safe and efficient operation of vital facilities for years to come.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
